Electric Chain hoist
If you want buy this product,You can contact us via the contact details below
Description
Electric Chain hoist is typical unique optimal structure in shortening the distance between the machine body and the beam tracks, applicable to operations in side low buildings, especially suitable for use in temporarily erected plant buildings or on the sites where expansion of effective hoisting spaces inside the buildings is required the Most important parts of the Machine is Chain and brake system.
Loading capacity: 0.5~50ton or customized design
Lifting height: 3~130m or customized design
Lifting speed: single or double speed 0.54~11.8m/min or customized design
Power supply: 220~690V,50/60HZ,three phase or customized design
Application
Electric chain hoist is widely used in Factory, workshop, warehouse, store, logistic, dock, port, freight yard, construction building, mine, etc.
Feature
* Electric Chain Hoist is highly effective and Compact Aluminum Body
* Electric chain hoist is light weight
* With Extremely durable and reliable Pull Rotor Motor Brake.
* Durable Push-Button Pendant for easy, one-handed operation
* Easy Maintenance, fast, easy, and trouble free
* Long-Life Friction Clutch protects hoist from damage and prevents over winding
* Suction rotary motor brake, precisely and effectively make the hoist stop running, even when low power.
* Low-noise transmission gear: intensive alloy steel are soaked in the oil so that the hoist will serve longer life.
Technical Parameter
| Model | CK-0.5 | CK-1 | CK-1.5 | CK-2 | CK-3 | CK-5 | CK-10 | CK-20 | |
|---|---|---|---|---|---|---|---|---|---|
| Capacity (Ton) | 0.5 | 1 | 1.5 | 2 | 3 | 5 | 10 | 20 | |
| Standard Lifting Height (M) | 2.5 | 2.5 | 2.5 | 3 | 3 | 3 | 3 | 3 | |
| Running test load (Kn) | 7.5 | 15 | 22.5 | 30 | 45 | 77 | 150 | 300 | |
| Effort required to lift max. Load (N) | 231 | 309 | 320 | 360 | 340 | 414 | 414 | 828 | |
| Headroom Him (MM) | 270 | 317 | 339 | 414 | 465 | 636 | 798 | 890 | |
| No. of chain strand | 1 | 1 | 1 | 1 | 2 | 2 | 4 | 8 | |
| Load Chain Diameter (mm) | 6 | 6 | 8 | 8 | 8 | 10 | 10 | 10 | |
|
Dimensions (MM) |
A | 130 | 140 | 161 | 161 | 161 | 186 | 207 | 215 |
| B | 127 | 158 | 187 | 187 | 210 | 253 | 398 | 650 | |
| C | 270 | 317 | 399 | 414 | 465 | 636 | 798 | 890 | |
| Hook Opening | 30 | 34 | 38 | 41 | 48 | 52 | 64 | 85 | |
| Net weight (kg) | 11.25 | 11.5 | 17.4 | 22.2 | 26.2 | 37.7 | 72 | 160 | |
